Fireworks Fuse Insertion Machine: Automatic Fuse Feeding, Cutting and Insertion
Manual fuse insertion is repetitive, slow and keeps operators close to the product. A fireworks fuse insertion machine automates feeding, cutting and inserting fuse so each product gets the same fuse length and position, while operators supervise from a safer distance.
How the machine works
Fuse is fed from a reel through guides, cut to the programmed length and placed into the tube or cake at the programmed positions. Servo axes position the insertion head over each target, so the machine can follow different layouts by loading a stored program instead of changing hardware.
Key features
- Automatic fuse feeding, cutting and insertion in one station
- Programmable insertion positions for different product layouts
- Consistent fuse length to support product quality control
- Remote start/stop and monitoring from outside the work zone
- Anti-static design, grounding and protective guarding
- Integration with upstream assembly and downstream packaging conveyors
Where fuse insertion fits in the line
Fuse insertion normally follows cake or tube assembly and precedes wrapping and packaging. Linking these stations with conveyors removes manual transfer, reduces work-in-progress inside hazardous buildings and keeps line output steady.
Frequently asked questions
Which products can the fireworks fuse insertion machine handle?
It can be configured for cakes, roman candles and other tube products. Insertion programs are set per product layout.
Does the machine also cut the fuse?
Yes. Feeding, cutting and insertion are combined in one station for consistent fuse length.
How does automation improve safety?
Operators load material and supervise remotely instead of handling each product, which reduces exposure time in the work zone.
What product sizes and fuse lengths does the fuse insertion machine handle?
Our automated fuse insertion and cutting device handles products 10–50 mm in diameter and 50–300 mm long, and inserts fuses at lengths of 10–200 mm with an accuracy of ±0.5 mm.
How fast is the fuse insertion machine?
It inserts fuses at speeds of up to 120 pieces per minute, with fuse cutting integrated in the same device.
What power supply and floor space does the fuse insertion machine need?
The device requires an input voltage of AC220V/50Hz, consumes approximately 1.5 kW in operation, and measures approximately L1200 × W800 × H1500 mm, suitable for small to medium-sized production facilities.
